Semi Automatic Panel Saw Machine TS 100

(0 reviews)

Specifications

Item Code 48W8AE
Model TS 100
Net Weight 4500 kg
Updated on2026-03-04
Total Installed Power Rating 12 kW
Information on technical characteristics, the delivery set, the country of manufacture and the appearance of the goods is for reference only and is based on the latest information available at the time of publications.

Additional Information

Features

  • This machine features a solid supporting structure with a phenol coated working table grooved to allow smooth passage of grippers and plastic wheels over galvanized supporting tables
  • It includes an electronically controlled motorized pusher or positioner with variable linear speed and six pneumatic clamping grippers for secure panel handling, along with automatic side alignment on the cutting line for precision
  • The setup comprises one 2200 mm phenol coated supporting table with fence and measuring stops, plus two auxiliary front tables for additional support
  • The saw carriage operates at variable speed from 0 to 100 m/min via an electronic variator and allows grooving operations on panels
  • A dedicated personal computer provides full machine control with Windows based graphic software to manage and visualize lengthwise and cross cuts on the same panel simultaneously, with direct connection to office systems via CD or network
