Funke CP Universal Cooler Quality Heat Exchanger 250 Degree C

Features

• Technical The FUNKE heat exchanger type CP is a heat exchanger with straight internal tubes and removable tube bundle whose fixed tube-sheet is clamped in between the shell side and tube side device flanges by means of two flat seals and bolts The movable tubesheet, floating due to the combination of two sealing rings and a leakage ring between the device flanges, protects against a mixing of the shell side and tube side flowing media In the case of leakages due to a single or both selaing rings being defective the pertinent media always escape towards the outside through signal bores on the circum-ference of the leakage ring All seals of this design seal against atmosphere The tube/tubesheet connections are produced by appro-priate tube expand rollings or tube weldings in accordance with the construction regulations, material combinations and operating media as well as the maximum permissible operating parameters (P/T) Naturally, to avoid gap cor-rosion, after a tube welding the internal tubes are roll expanded again The connection and guide chambers are available in differ-ent versions, which can be produced by a tube side single-pass, two-pass or four pass design and whose selection is effected in accordance with the standards required and with fluid engineering aspects Venting and draining points as well as a corresponding foot construction are designed in relation to the installation position
